304 Stainless Steel Wire Mesh

316 L Stainless Steel Wire Mesh ms-welded-mesh-

We are engaged in offering 304 Stainless Steel Wire Mesh, which is extremely praised in the market. Owing to high demand, professionals make these products in varied patterns.

Enquiry Form
Categories: ,
Usage/Application Domestic
Material Stainless Steel
Material Grade 304
Wire Diameter 0.376 X 0.274 mm to 0.035 X 0.025 mm
Mesh Size 24 X 110 mm to 325 X 2300 mm



Specifications:

WIRE CLOTH -DUTCH WEAVES
(Available in Stainless Steel AISI 304, 304L, 316 & 316L Specification)
Sl. Mesh Gauge Wire  Dia WT/SQ Mtr Kgs. Weave
No. In MM
1 24 X 110 28 X 32 0.376 X 0.274 2.872 Plain Dutch
2 50 X 250 38.5 X 41 0.140 X 0.112 1.015 Plain Dutch
3 80 X 400 40 X 45.5 0.122 X 0.063 0.684 Plain Dutch
4 80 X 700 42 X 44 0.102 X 0.081 0.89 Twill Dutch
5 100 X 600 42 X 45.5 0.102 X 0.063 0.843 Twill Dutch
6 120 X 600 42 X 45.5 0.102 X 0.063 0.859 Twill Dutch
7 170 X 1400 45.5 X 48 0.063 X 0.040 0.178 Twill Dutch
8 200 X 600 47 X 48 0.050 X 0.040 0.36 Twill Dutch
9 325 X 2300 48.5 X 50 0.035 X 0.025 0.452 Twill Dutch
